Treadpace Precision Motion Solutions
Integrated Catalog

Every Model. Every Spec. One Place.

Filter by series, search by model number (LCISC / LCID5), or click any card for full specifications.

Series
LCISC LCISC28-P1A3 28 mm Integrated Stepper Servo — 0.065 N·m 3
28 mm Integrated Stepper Servo — 0.065 N·m
The LCISC28 Series is a compact 28 mm stepper servo motor designed for applications requiring precise positioning, reliable motion control, and a small installation footprint. Featuring 15-bit single-turn absolute feedback, the motor provides accurate position monitoring without requiring a separate external encoder. With an ultra-compact frame and holding torque of up to 0.12 N·m, the LCISC28 Series is well suited for compact automation equipment, precision positioning systems, robotics, laboratory equipment, and other space-constrained motion-control applications. The series offers multiple motor configurations with different current, resistance, inductance, torque, weight, and length specifications, allowing users to select the appropriate model for their application.
0.065 N·m · 1.8 ° · 48.1 mm
LCISC LCISC28-P2A3 28 mm Integrated Stepper Servo — 0.095 N·m 3
28 mm Integrated Stepper Servo — 0.095 N·m
The CISC28-P2A3 is a compact 28 mm stepper servo motor designed for precise positioning and reliable motion control in space-constrained applications. It features a 1.8° step angle, 0.67 A current, 6.8 Ω resistance, 5.5 mH inductance, and 0.095 N·m holding torque, with a lightweight 0.17 kg design and 61 mm length. Equipped with a 15-bit single-turn absolute encoder, it provides accurate position feedback and is suitable for automation equipment, robotics, precision positioning systems, and other compact motion-control applications.
0.095 N·m · 1.8 ° · 61 mm
LCISC LCISC28-P3A3 28 mm Integrated Stepper Servo — 0.12 N·m 3
28 mm Integrated Stepper Servo — 0.12 N·m
The LCISC28-P3A3 is a compact 28 mm stepper servo motor designed for precise positioning and reliable motion control in space-constrained applications. It features a 1.8° step angle, 0.67 A current, 8.8 Ω resistance, 8.0 mH inductance, and 0.12 N·m holding torque, with a lightweight 0.22 kg design and 67 mm length. Equipped with a 15-bit single-turn absolute encoder, it provides accurate position feedback and is suitable for automation equipment, robotics, precision positioning systems, and other compact motion-control applications.
0.12 N·m · 1.8 ° · 67 mm
LCISC LCISC42-P1A3 42 mm Integrated Stepper Servo — 0.26 N·m 3
42 mm Integrated Stepper Servo — 0.26 N·m
The LCISC42-P1A3 is a 42 mm integrated stepper servo motor designed for precise and reliable motion control in compact automation applications. It features a 1.8° step angle, 1.33 A current, 1.8 Ω resistance, 2.5 mH inductance, and 0.26 N·m holding torque, with a compact 55.4 mm length. Supporting Pulse, RS485, and CANopen control interfaces, this integrated stepper servo provides accurate positioning and efficient motion control for robotics, automation equipment, precision machinery, and other demanding applications.
0.26 N·m · 1.8 ° · 55.4 mm
LCISC LCISC42-P2A3 42 mm Integrated Stepper Servo — 0.42 N·m 3
42 mm Integrated Stepper Servo — 0.42 N·m
The LCISC42-P2A3 is a 42 mm integrated stepper servo motor designed for precise, stable, and reliable motion control in automation and compact machinery applications. It features a 1.8° step angle, 1.7 A current, 1.2 Ω resistance, 2.8 mH inductance, and 0.42 N·m holding torque, with a compact 61.4 mm length. Supporting Pulse, RS485, and CANopen control interfaces, this integrated stepper servo provides accurate positioning and efficient motion control for robotics, automation equipment, precision machinery, and other demanding applications.
0.42 N·m · 1.8 ° · 61.4 mm
LCISC LCISC42-P3A3 42 mm Integrated Stepper Servo — 0.5 N·m 3
42 mm Integrated Stepper Servo — 0.5 N·m
The LCISC42-P3A3 is a 42 mm integrated stepper servo motor designed for precise, stable, and reliable motion control in automation and compact machinery applications. It features a 1.8° step angle, 1.68 A current, 1.55 Ω resistance, 2.8 mH inductance, and 0.5 N·m holding torque, with a compact 69.9 mm length. Supporting Pulse, RS485, and CANopen control interfaces, this integrated stepper servo provides accurate positioning and efficient motion control for robotics, automation equipment, precision machinery, and other demanding applications.
0.5 N·m · 1.8 ° · 69.9 mm
LCISC LCISC42-P4A3 42 mm Integrated Stepper Servo — 0.73 N·m 3
42 mm Integrated Stepper Servo — 0.73 N·m
The **LCISC42-P4A3** is a 42 mm integrated stepper servo motor designed for precise, stable, and reliable motion control in automation and compact machinery applications. It features a **1.8° step angle**, **1.7 A current**, **2.6 Ω resistance**, **6.2 mH inductance**, and **0.73 N·m holding torque**, with an **81.9 mm length**. Supporting **Pulse, RS485, and CANopen** control interfaces, this integrated stepper servo provides accurate positioning and efficient motion control for robotics, automation equipment, precision machinery, and other demanding applications.
0.73 N·m · 1.8 ° · 81.9 mm
LCISC LCISC57-P1A3 57 mm Integrated Stepper Servo — 0.55 N·m 2
57 mm Integrated Stepper Servo — 0.55 N·m
The LCISC57-P1A3 is a 57 mm integrated stepper servo motor designed for precise, stable, and reliable motion control in automation and industrial applications. It features a 1.8° step angle, 2.8 A current, 0.70 Ω resistance, 1.4 mH inductance, and 0.55 N·m holding torque, with a compact 61.5 mm length. Supporting Pulse, RS485, and CANopen control interfaces, this integrated stepper servo provides accurate positioning and efficient motion control for robotics, automation equipment, precision machinery, and other demanding applications.
0.55 N·m · 1.8 ° · 61.5 mm
LCISC LCISC57-P2A3 57 mm Integrated Stepper Servo — 1.2 N·m 2
57 mm Integrated Stepper Servo — 1.2 N·m
The LCISC57-P2A3 Integrated Stepper Servo Motor combines the precise positioning of a stepper motor with servo-style closed-loop control, providing reliable motion performance for industrial automation and precision positioning applications. With a 1.8° step angle, 1.2 N·m holding torque, and a 57 mm motor frame, it delivers stable and accurate motion while maintaining a compact design. The motor is rated at 2.8 A with a 0.9 Ω resistance and 3.0 mH inductance, making it suitable for demanding motion-control applications. Weighing approximately 0.8 kg and measuring 75 mm in length, the LCISC57-P2A3 offers a practical balance between torque, size, and installation space.
1.2 N·m · 1.8 ° · 75 mm
LCISC LCISC57-P3A3 57 mm Integrated Stepper Servo — 1.89 N·m 2
57 mm Integrated Stepper Servo — 1.89 N·m
The LCISC57-P3A3 Integrated Stepper Servo Motor combines the high positioning accuracy of a stepper motor with servo-style control for stable, responsive, and reliable motion performance. Designed with a 57 mm frame size, 1.8° step angle, and 1.89 N·m torque, it is well suited for industrial automation and precision motion-control applications. With a 2.8 A rated current, 1.1 Ω resistance, and 3.6 mH inductance, the LCISC57-P3A3 provides consistent motor performance for demanding applications. Its 96 mm length and approximately 1.2 kg weight make it a robust option where higher torque and dependable positioning are required.
1.89 N·m · 1.8 ° · 96 mm
LCISC LCISC57-P4A3 57 mm Integrated Stepper Servo — 2.2 N·m 2
57 mm Integrated Stepper Servo — 2.2 N·m
The LCISC57-P4A3 Integrated Stepper Servo Motor is designed for precision motion control applications requiring higher torque, stable operation, and accurate positioning. Combining stepper motor technology with integrated servo control, it provides reliable and responsive motion performance for industrial automation and machinery. Featuring a 57 mm frame size, 1.8° step angle, and 2.2 N·m torque, the LCISC57-P4A3 delivers strong output in a compact motor package. It operates at 3.0 A, with 1.4 Ω resistance and 4.5 mH inductance. With a 102.5 mm length and approximately 1.3 kg weight, it is suitable for applications where increased torque and dependable positioning are required.
2.2 N·m · 1.8 ° · 102.5 mm
LCISC LCISC57-P5A3 57 mm Integrated Stepper Servo — 2.8 N·m 2
57 mm Integrated Stepper Servo — 2.8 N·m
The LCISC57-P5A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for applications requiring precise positioning, stable operation, and reliable performance. By combining stepper motor technology with integrated servo control, it provides accurate and responsive motion for industrial automation and machinery. Featuring a 57 mm frame size, 1.8° step angle, and 2.8 N·m torque, the LCISC57-P5A3 provides increased torque output for demanding motion applications. It operates at 4.2 A, with 0.75 Ω resistance and 3.0 mH inductance. With a 116.5 mm length and approximately 1.6 kg weight, this motor is suitable for systems requiring higher torque within a compact industrial motor design.
2.8 N·m · 1.8 ° · 116.5 mm
LCISC LCISC57-P6A3 57 mm Integrated Stepper Servo — 3 N·m 2
57 mm Integrated Stepper Servo — 3 N·m
The LCISC57-P6A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation and precision positioning applications. Combining stepper motor technology with integrated servo control, it delivers accurate positioning, stable operation, and reliable motion performance. With a 57 mm frame size, 1.8° step angle, and 3.0 N·m torque, the LCISC57-P6A3 provides strong output for applications requiring increased load-handling capability. It operates at 4.2 A, with 0.9 Ω resistance and 3.8 mH inductance. The motor has a 132 mm length and weighs approximately 1.8 kg, making it suitable for larger and more demanding motion systems.
3 N·m · 1.8 ° · 132 mm
LCISC LCISC60-P1A3 60 mm Integrated Stepper Servo — 1.6 N·m 2
60 mm Integrated Stepper Servo — 1.6 N·m
The LCISC60-P1A3 Integrated Stepper Servo Motor is a compact, high-performance motion-control solution designed for applications requiring precise positioning, smooth operation, and reliable torque output. Combining stepper motor technology with integrated servo control, it provides responsive and accurate motion for industrial automation systems. Featuring a 60 mm frame size, 1.8° step angle, and 1.6 N·m torque, the LCISC60-P1A3 delivers strong performance in a compact package. It operates at 4.2 A, with 0.5 Ω resistance and 1.4 mH inductance. With a 73.7 mm length and approximately 0.8 kg weight, it is well suited for applications where space efficiency and dependable motion control are important.
1.6 N·m · 1.8 ° · 73.7 mm
LCISC LCISC60-P2A3 60 mm Integrated Stepper Servo — 2 N·m 2
60 mm Integrated Stepper Servo — 2 N·m
The LCISC60-P2A3 Integrated Stepper Servo Motor is a reliable motion-control solution designed for applications requiring precise positioning, stable operation, and consistent torque performance. Combining stepper motor technology with integrated servo control, it delivers accurate and responsive motion for industrial automation and machinery. With a 60 mm frame size, 1.8° step angle, and 2.0 N·m torque, the LCISC60-P2A3 provides strong performance for a wide range of precision motion applications. It operates at 4.2 A, with 0.6 Ω resistance and 1.8 mH inductance. The motor has a 87.2 mm length and weighs approximately 1.3 kg, offering a practical balance of torque, size, and installation flexibility.
2 N·m · 1.8 ° · 87.2 mm
LCISC LCISC60-P3A3 60 mm Integrated Stepper Servo — 2.8 N·m
60 mm Integrated Stepper Servo — 2.8 N·m
The LCISC60-P3A3 Integrated Stepper Servo Motor is a high-performance motion-control solution designed for applications requiring precise positioning, stable operation, and reliable torque output. Combining stepper motor technology with integrated servo control, it provides accurate and responsive motion for industrial automation and precision machinery. Featuring a 60 mm frame size, 1.8° step angle, and 2.8 N·m torque, the LCISC60-P3A3 delivers increased torque for demanding motion-control applications. It operates at 4.2 A, with 0.8 Ω resistance and 3.0 mH inductance. With a 108.2 mm length and approximately 1.5 kg weight, it offers a strong balance of torque, durability, and installation flexibility.
2.8 N·m · 1.8 ° · 108.2 mm
LCISC LCISC60-P4A3 60 mm Integrated Stepper Servo — 3.8 N·m
60 mm Integrated Stepper Servo — 3.8 N·m
The LCISC60-P4A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and reliable motion performance. Featuring a 60 mm frame size, 1.8° step angle, and 3.8 N·m torque, the LCISC60-P4A3 delivers strong torque output for applications requiring increased load-handling capability. It operates at 4.2 A, with 0.75 Ω resistance and 3.6 mH inductance. With a 121.2 mm length and approximately 1.8 kg weight, this motor is well suited for demanding motion systems where high torque and dependable positioning are required.
3.8 N·m · 1.8 ° · 121.2 mm
LCISC LCISC60-P5A3 60 mm Integrated Stepper Servo — 4.1 N·m 4
60 mm Integrated Stepper Servo — 4.1 N·m
The LCISC60-P5A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and dependable motion performance. Featuring a 60 mm frame size, 1.8° step angle, and 4.1 N·m torque, the LCISC60-P5A3 delivers strong output for applications requiring higher load-handling capability. It operates at 4.2 A, with 1.0 Ω resistance and 3.8 mH inductance. With a 130.7 mm length and approximately 2.0 kg weight, it is well suited for demanding motion systems where high torque and reliable positioning are essential.
4.1 N·m · 1.8 ° · 130.7 mm
LCISC LCISC86-P6A3 86 mm Integrated Stepper Servo — 12 N·m 2
86 mm Integrated Stepper Servo — 12 N·m
The LCISC86-P6A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation, CNC, robotics, and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and reliable performance under demanding loads. Featuring an 86 mm frame size, 1.8° step angle, and an impressive 12 N·m torque, the LCISC86-P6A3 is designed for applications requiring substantial torque output and dependable motion control. It operates at 6.0 A, with 0.44 Ω resistance and 5.5 mH inductance. With a 182.3 mm length and approximately 6.24 kg weight, this robust motor is suitable for larger and heavier-duty motion systems.
12 N·m · 1.8 ° · 182.3 mm
LCISC LCISC86-P1A3 86 mm Integrated Stepper Servo — 4.5 N·m
86 mm Integrated Stepper Servo — 4.5 N·m
The LCISC86-P1A3 Integrated Stepper Servo Motor is a robust motion-control solution designed for industrial automation, CNC machinery, robotics, and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and dependable motion performance. Featuring an 86 mm frame size, 1.8° step angle, and 4.5 N·m torque, the LCISC86-P1A3 delivers reliable torque for a wide range of demanding motion applications. It operates at 6.0 A, with 0.37 Ω resistance and 3.4 mH inductance. With a 107.8 mm length and approximately 2.54 kg weight, this motor offers a strong balance of torque, compact dimensions, and robust performance.
4.5 N·m · 1.8 ° · 107.8 mm
LCISC LCISC86-P2A3 86 mm Integrated Stepper Servo — 6.5 N·m
86 mm Integrated Stepper Servo — 6.5 N·m
The LCISC86-P2A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for industrial automation, CNC machinery, robotics, and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and dependable motion performance. Featuring an 86 mm frame size, 1.8° step angle, and 6.5 N·m torque, the LCISC86-P2A3 delivers strong and reliable torque for demanding motion applications. It operates at 6.0 A, with 0.47 Ω resistance and 4.18 mH inductance. With a 127.3 mm length and approximately 3.24 kg weight, this motor offers a practical balance of torque, compact design, and robust performance.
6.5 N·m · 1.8 ° · 127.3 mm
LCISC LCISC86-P3A3 86 mm Integrated Stepper Servo — 7 N·m 3
86 mm Integrated Stepper Servo — 7 N·m
The LCISC86-P3A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for industrial automation, CNC machinery, robotics, and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and dependable motion performance. Featuring an 86 mm frame size, 1.8° step angle, and 7.0 N·m torque, the LCISC86-P3A3 provides strong torque output for applications requiring reliable and controlled motion. It operates at 6.0 A, with 0.36 Ω resistance and 2.8 mH inductance. With a 130.8 mm length and approximately 3.94 kg weight, this robust motor offers a strong balance of torque, size, and mechanical performance.
7 N·m · 1.8 ° · 130.8 mm
LCISC LCISC86-P4A3 86 mm Integrated Stepper Servo — 8.5 N·m 2
86 mm Integrated Stepper Servo — 8.5 N·m
The LCISC86-P4A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation and precision positioning applications. Combining stepper motor technology with integrated servo control, it provides accurate positioning, stable operation, and reliable performance for heavy-duty motion systems. Featuring an 86 mm frame size, 1.8° step angle, and 8.5 N·m torque, the LCISC86-P4A3 delivers strong torque output for applications requiring dependable motion and increased load capacity. It operates at 6.0 A, with 0.36 Ω resistance and 3.8 mH inductance. With a 144.3 mm length and approximately 4.44 kg weight, this robust motor is suitable for demanding industrial applications where high torque and precise positioning are essential.
8.5 N·m · 1.8 ° · 144.3 mm
LCISC LCISC86-P5A3 86 mm Integrated Stepper Servo — 9.5 N·m 2
86 mm Integrated Stepper Servo — 9.5 N·m
The LCISC86-P5A3 Integrated Stepper Servo Motor is a high-torque motion-control solution designed for demanding industrial automation and precision positioning applications. Combining stepper motor technology with integrated servo control, it delivers accurate positioning, stable operation, and reliable motion performance. Featuring an 86 mm frame size, 1.8° step angle, and 9.5 N·m torque, the LCISC86-P5A3 provides substantial torque output for applications requiring strong and dependable motion. It operates at 6.0 A, with 0.58 Ω resistance and 6.5 mH inductance. With a 155.8 mm length and approximately 4.74 kg weight, this robust motor is suitable for larger motion systems and heavier mechanical loads.
9.5 N·m · 1.8 ° · 155.8 mm
LCID5 LCID542-P01A 42 mm Integrated DC Servo — 26 W
42 mm Integrated DC Servo — 26 W
The LCIDS42-P01A Integrated Servo Motor is a compact and precise motion-control solution designed for automation equipment, positioning systems, and applications requiring fast and accurate motor control. With a 26 W rated power, 24 VDC operating voltage, and maximum speed of 4000 rpm, it provides responsive performance in a compact package. The motor delivers 0.0625 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise motion control. With a compact 61 mm length, the LCIDS42-P01A is well suited for equipment where installation space is limited while maintaining accurate and reliable servo performance.
0.0625 N·m · 26 W · 61 mm
LCID5 LCID542-P02A 42 mm Integrated DC Servo — 53 W
42 mm Integrated DC Servo — 53 W
The LCIDS42-P02A Integrated Servo Motor is a compact, high-performance motion-control solution designed for automation equipment and precision positioning applications. With 53 W rated power, a 24 VDC operating voltage, and a maximum speed of 4000 rpm, it delivers fast, responsive, and accurate motion performance. The motor provides 0.125 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise control. With an 81 mm length, the LCIDS42-P02A offers increased power and torque while maintaining a compact design suitable for space-conscious machinery.
0.125 N·m · 53 W · 81 mm
LCID5 LCID542-P03A 42 mm Integrated DC Servo — 78 W
42 mm Integrated DC Servo — 78 W
The LCIDS42-P03A Integrated Servo Motor is a compact, high-performance motion-control solution designed for industrial automation, precision positioning, and equipment requiring fast and accurate movement. With 78 W rated power, 24 VDC operating voltage, and a maximum speed of 4000 rpm, it delivers responsive and reliable servo performance. The motor provides 0.185 N·m torque and incorporates a 17-bit encoder for high-resolution position feedback and precise motion control. With a 101 mm length, the LCIDS42-P03A provides increased power and torque while maintaining a compact form factor for space-conscious machinery.
0.185 N·m · 78 W · 101 mm
LCID5 LCID542-P04A 42 mm Integrated DC Servo — 78 W
42 mm Integrated DC Servo — 78 W
The LCIDS42-P04A Integrated Servo Motor is a compact and reliable motion-control solution designed for precision positioning, automation equipment, and applications requiring accurate and responsive motor control. With 78 W rated power, 24 VDC operating voltage, and a maximum speed of 3000 rpm, it delivers stable and controlled motion performance. The motor provides 0.25 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 120 mm length, the LCIDS42-P04A offers increased torque performance while maintaining a compact design suitable for a wide range of automated machinery.
0.25 N·m · 78 W · 120 mm
LCID5 LCID557-P02A 57 mm Integrated DC Servo — 140 W
57 mm Integrated DC Servo — 140 W
The LCIDS57-P02A Integrated Servo Motor is a high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring accurate and responsive movement. With 140 W rated power, a 24/36 VDC operating voltage, and a maximum speed of 3000 rpm, it provides reliable and efficient motion performance. The motor delivers 0.45 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 121 mm length, the LCIDS57-P02A provides increased power and torque while maintaining a compact form factor suitable for a wide range of automated equipment.
0.45 N·m · 140 W · 121 mm
LCID5 LCID557-P03A 57 mm Integrated DC Servo — 200 W
57 mm Integrated DC Servo — 200 W
The LCIDS57-P03A Integrated Servo Motor is a high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring accurate, responsive, and reliable movement. With 200 W rated power, a 36/48 VDC operating voltage, and a maximum speed of 3000 rpm, it provides strong and stable motion performance for demanding applications. The motor delivers 0.64 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 141 mm length, the LCIDS57-P03A provides increased power and torque while maintaining a practical form factor for automated machinery and motion systems.
0.64 N·m · 200 W · 141 mm
LCID5 LCID557-P01A 57 mm Integrated DC Servo — 91 W
57 mm Integrated DC Servo — 91 W
The LCIDS57-P01A Integrated Servo Motor is a compact, high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring accurate and responsive motor control. With 91 W rated power, a flexible 24/36 VDC operating voltage, and a maximum speed of 3000 rpm, it delivers stable and efficient motion performance. The motor provides 0.29 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 101 mm length, the LCIDS57-P01A offers a practical combination of power, torque, and compact dimensions for a wide range of automated equipment.
0.29 N·m · 91 W · 101 mm
LCID5 LCID560-P01A 60 mm Integrated DC Servo — 200 W
60 mm Integrated DC Servo — 200 W
The LCIDS60-P01A Integrated Servo Motor is a compact, high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring accurate and responsive movement. With 200 W rated power, 24 VDC operating voltage, and a maximum speed of 3000 rpm, it provides reliable and efficient motion performance. The motor delivers 0.64 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a compact 94 mm length, the LCIDS60-P01A offers a strong combination of power, torque, and space efficiency, making it suitable for a wide range of automated equipment.
0.64 N·m · 200 W · 94 mm
LCID5 LCID560-P02A 60 mm Integrated DC Servo — 400 W
60 mm Integrated DC Servo — 400 W
The LCIDS60-P02A Integrated Servo Motor is a powerful and compact motion-control solution designed for industrial automation, precision positioning, and machinery requiring high-performance and responsive movement. With 400 W rated power, 48 VDC operating voltage, and a maximum speed of 3000 rpm, it delivers strong and reliable motion performance for demanding applications. The motor provides 1.27 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 112 mm length, the LCIDS60-P02A offers an effective combination of high power, substantial torque, and compact dimensions for automated machinery and motion-control systems.
1.27 N·m · 400 W · 112 mm
LCID5 LCIDS80-P02A 80 mm Integrated DC Servo — 1000 W
80 mm Integrated DC Servo — 1000 W
The LCIDS60-P02A Integrated Servo Motor is a high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring high power, accurate movement, and responsive control. With 400 W rated power, 48 VDC operating voltage, and a maximum speed of 3000 rpm, it delivers reliable performance for demanding motion applications. The motor provides 1.27 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a 112 mm length, the LCIDS60-P02A offers a strong combination of power, torque, and compact dimensions for automated machinery and precision motion systems.
3.2 N·m · 1000 W · 175 mm
LCID5 LCIDS80-P01A 80 mm Integrated DC Servo — 750 W
80 mm Integrated DC Servo — 750 W
The LCIDS60-P01A Integrated Servo Motor is a compact, high-performance motion-control solution designed for industrial automation, precision positioning, and machinery requiring accurate and responsive movement. With 200 W rated power, 24 VDC operating voltage, and a maximum speed of 3000 rpm, it provides reliable and efficient motion performance. The motor delivers 0.64 N·m torque and features a 17-bit encoder for high-resolution position feedback and precise servo control. With a compact 94 mm length, the LCIDS60-P01A offers a strong combination of power, torque, and space efficiency, making it suitable for a wide range of automated equipment.
2.4 N·m · 750 W · 155 mm
FTM 3811-2410 38 mm Frameless Torque Motor — 0.05 N·m
38 mm Frameless Torque Motor — 0.05 N·m
The 3811-2410 is a compact 38 mm frameless torque motor designed for direct integration into space-constrained rotary mechanisms. With a 24 VDC winding, 5000 rpm rated speed, and 0.05 N·m continuous torque, it provides smooth, backlash-free motion for robotic joints, gimbals, and precision actuators. The stator and rotor are supplied as separate assemblies, allowing the motor to be embedded directly into the mechanical structure. Sintered NdFeB magnets and Class B insulation ensure reliable performance across a -10 to +40 °C operating range. Its low profile and 0.115 kg mass make it ideal for miniature robotics and portable equipment.
0.05 N·m · 11 mm
FTM 4308-3650 43 mm Frameless Torque Motor — 0.15 N·m
43 mm Frameless Torque Motor — 0.15 N·m
The 4308-3650 is a 43 mm frameless torque motor delivering 0.15 N·m of continuous torque at 5000 rpm from a 36 VDC supply. Its separate stator and rotor construction enables seamless integration into custom rotary joints, exoskeleton actuators, and precision automation modules. The 14-pole, 3-phase design provides high torque density and low cogging for smooth motion. With a 0.085 kg mass and 15.5 mm body length, it is well suited to applications where compact size and direct-drive performance are critical.
0.15 N·m · 15.5 mm
FTM 5086-4850 50 mm Frameless Torque Motor — 0.15 N·m
50 mm Frameless Torque Motor — 0.15 N·m
The 5086-4850 is a 50 mm frameless torque motor rated at 0.15 N·m and 5000 rpm from a 48 VDC supply. Its 3 A continuous current and 20 mm body length make it a balanced choice for continuous-duty applications such as robotic wrist joints and automated positioning stages. The frameless architecture eliminates the need for a separate housing, reducing overall system size and improving mechanical stiffness. Sintered NdFeB magnets and Class B insulation support reliable operation in industrial environments.
0.15 N·m · 20 mm
FTM 5015-4835 50 mm Frameless Torque Motor — 0.5 N·m
50 mm Frameless Torque Motor — 0.5 N·m
The 5015-4835 is a higher-torque 50 mm frameless torque motor providing 0.5 N·m continuous torque at 3500 rpm from a 48 VDC supply. With a 3 A rating and 26 mm body length, it is designed for demanding rotary applications where direct drive eliminates backlash and improves response. Typical uses include robotic joints, precision gimbals, and medical equipment. The 20-pole, 3-phase stator and sintered NdFeB rotor deliver high torque density in a compact, frameless package.
0.5 N·m · 26 mm
FTM 6023-4840 60 mm Frameless Torque Motor — 0.45 N·m
60 mm Frameless Torque Motor — 0.45 N·m
The 6023-4840 is a 60 mm frameless torque motor delivering 0.45 N·m continuous torque at 4000 rpm from a 48 VDC supply. Its 5 A rating and 30 mm body length provide a robust solution for heavier robotic joints, industrial automation, and precision positioning systems. The separate stator and rotor assemblies simplify mechanical integration and reduce system footprint. Peak torque reaches 1.35 N·m, making it suitable for intermittent high-load maneuvers.
0.45 N·m · 30 mm
FTM 7024-4836 70 mm Frameless Torque Motor — 0.55 N·m
70 mm Frameless Torque Motor — 0.55 N·m
The 7024-4836 is a 70 mm frameless torque motor offering 0.55 N·m continuous torque at 3650 rpm from a 48 VDC supply. With a 5.12 A rating and 1.65 N·m peak torque, it provides strong output for industrial robotics, automated guided vehicles, and large gimbals. The 20-pole, 3-phase design and sintered NdFeB magnets ensure high torque density and smooth operation. Its 24 mm body length and 0.217 kg mass make it a compact yet powerful direct-drive solution.
0.55 N·m · 24 mm
FTM 7032-4835 70 mm Frameless Torque Motor — 1.9 N·m
70 mm Frameless Torque Motor — 1.9 N·m
The 7032-4835 is a high-torque 70 mm frameless torque motor rated at 1.9 N·m continuous torque and 3500 rpm from a 48 VDC supply. Designed for heavy-duty rotary applications, it delivers up to 3 N·m peak torque for intermittent loads. The separate stator and rotor allow direct integration into robotic joints, exoskeletons, and industrial machinery where backlash-free motion and high stiffness are essential. With a 32 mm body length and 0.32 kg mass, it balances power and compactness.
1.9 N·m · 32 mm
FTM 9626-3630 96 mm Frameless Torque Motor — 1.2 N·m
96 mm Frameless Torque Motor — 1.2 N·m
The 9626-3630 is the largest frameless torque motor in the series, featuring a 96 mm frame and delivering 1.2 N·m continuous torque at 3000 rpm from a 36 VDC supply. Its 3 A rating and 3.6 N·m peak torque support demanding applications such as large robotic joints, medical imaging gantries, and industrial automation. The 30-pole, 3-phase design with sintered NdFeB magnets ensures high torque density and smooth, precise motion. With a 20 mm body length and 0.26 kg mass, it provides substantial output in a compact frameless package.
1.2 N·m · 20 mm
LCM 1348-24222 13 mm Coreless Motor — 7.05 mN·m
13 mm Coreless Motor — 7.05 mN·m
The 1348-24222 is an ultra-compact 13 mm coreless motor delivering 15.7 W of power at 22200 rpm from a 24 VDC supply. With a 7.05 mN·m continuous torque and 0.94 A current, it offers fast acceleration and precise control for miniature applications such as medical devices, dental tools, and precision instruments. The four-pole, three-phase coreless construction eliminates cogging and provides smooth operation. Its 53.8 mm body length and 0.03 kg mass make it ideal for space-constrained designs.
7.05 mN·m · 15.7 W · 53.8 mm
LCM 1666-24619 16 mm Coreless Motor — 16 mN·m
16 mm Coreless Motor — 16 mN·m
The 1666-24619 is a 16 mm coreless motor capable of 61900 rpm and 99.2 W output from a 24 VDC supply. Delivering 16 mN·m of continuous torque at 4.88 A, it is designed for high-speed applications requiring rapid acceleration and precise speed control, such as dental handpieces, robotics, and centrifugal pumps. The coreless design minimizes rotor inertia and eliminates cogging, ensuring smooth, vibration-free operation. With a 66.2 mm body length and 0.083 kg mass, it packs high performance into a small frame.
16 mN·m · 99.2 W · 66.2 mm
LCM 2264-1853 22 mm Coreless Motor — 25.97 mN·m
22 mm Coreless Motor — 25.97 mN·m
The 2264-1853 is a 22 mm coreless motor designed for low-voltage applications, operating at 18 VDC and delivering 13.8 W at 5300 rpm. With 25.97 mN·m continuous torque and 1.1 A current, it is ideal for battery-powered devices, handheld tools, and portable medical equipment. The four-pole, three-phase coreless construction provides smooth, efficient operation with minimal cogging. Its 64.2 mm body length and 0.12 kg mass make it a compact and lightweight choice for mobile applications.
25.97 mN·m · 13.8 W · 64.2 mm
LCM 2260-48149 22 mm Coreless Motor — 39.89 mN·m
22 mm Coreless Motor — 39.89 mN·m
The 2260-48149 is a 22 mm coreless motor optimized for efficiency and smooth operation, delivering 59.6 W at 14900 rpm from a 48 VDC supply. With 39.89 mN·m continuous torque and 1.65 A current, it provides a balanced combination of speed and torque for applications such as medical pumps, laboratory equipment, and precision automation. The coreless design ensures low electrical noise and long service life. Its 60 mm body length and 0.135 kg mass make it suitable for compact, portable devices.
39.89 mN·m · 59.6 W · 60 mm
LCM 2270-48301 22 mm Coreless Motor — 41.9 mN·m
22 mm Coreless Motor — 41.9 mN·m
The 2270-48301 is a 22 mm coreless motor providing 126.2 W of power at 30100 rpm from a 48 VDC supply. With 41.9 mN·m continuous torque and 3.2 A current, it is well suited to industrial automation, medical equipment, and robotics where high power density and precise control are required. The four-pole, three-phase coreless winding delivers smooth, cog-free motion. Its 70.3 mm body length and 0.125 kg mass make it a compact solution for demanding applications.
41.9 mN·m · 126.2 W · 70.3 mm
LCM 2558-28157 25 mm Coreless Motor — 19.63 mN·m
25 mm Coreless Motor — 19.63 mN·m
The 2558-28157 is a 25 mm coreless motor delivering 30.9 W at 15700 rpm from a 28 VDC supply. With 19.63 mN·m continuous torque and 1.45 A current, it offers a balanced performance profile for compact automation, medical devices, and robotics. The coreless winding ensures low inertia and rapid response, while the four-pole, three-phase design minimizes vibration. Its 58 mm body length and 0.135 kg mass make it suitable for space-constrained motion systems.
19.63 mN·m · 30.9 W · 58 mm
LCM 2560-2895 25 mm Coreless Motor — 40.37 mN·m
25 mm Coreless Motor — 40.37 mN·m
The 2560-2895 is a 25 mm coreless motor providing 38.2 W at 9500 rpm from a 28 VDC supply. With 40.37 mN·m continuous torque and 1.6 A current, it is designed for medium-load applications requiring smooth, precise motion, such as laboratory equipment, automated dispensers, and medical instruments. The coreless construction eliminates cogging and reduces audible noise. Its 60 mm body length and 0.36 kg mass provide a robust yet compact solution.
40.37 mN·m · 38.2 W · 60 mm
LCM 2852-28103 28 mm Coreless Motor — 50.08 mN·m
28 mm Coreless Motor — 50.08 mN·m
The 2852-28103 is a 28 mm coreless motor delivering 51.6 W at 10300 rpm from a 28 VDC supply. With 50.08 mN·m continuous torque and 2.43 A current, it offers increased torque for robotics, precision machinery, and industrial automation. The four-pole, three-phase coreless design ensures smooth operation and high efficiency. Its 52.3 mm body length and 0.138 kg mass make it a compact powerhouse for demanding motion-control tasks.
50.08 mN·m · 51.6 W · 52.3 mm
LCM 2865-24117 28 mm Coreless Motor — 98.78 mN·m
28 mm Coreless Motor — 98.78 mN·m
The 2865-24117 is a high-torque 28 mm coreless motor rated at 115.2 W and 11700 rpm from a 24 VDC supply. With 98.78 mN·m continuous torque and 6.5 A current, it is engineered for demanding applications such as robotic actuators, medical devices, and industrial automation. The coreless winding provides fast acceleration and precise control, while the four-pole, three-phase construction minimizes vibration and noise. Its 50 mm body length and 0.205 kg mass deliver exceptional torque density in a compact frame.
98.78 mN·m · 115.2 W · 50 mm
LCM 3084-2482 30 mm Coreless Motor — 60.04 mN·m
30 mm Coreless Motor — 60.04 mN·m
The 3084-2482 is a 30 mm coreless motor delivering 49.2 W at 8200 rpm from a 24 VDC supply. With 60.04 mN·m continuous torque and 2.75 A current, it provides robust performance for industrial equipment, medical devices, and automation systems. The larger 30 mm frame accommodates a more powerful winding while maintaining smooth, cog-free operation. Its 84 mm body length and 0.31 kg mass make it suitable for applications requiring higher torque and durability.
60.04 mN·m · 49.2 W · 84 mm
LCM 3084-90223 30 mm Coreless Motor — 96.45 mN·m
30 mm Coreless Motor — 96.45 mN·m
The 3084-90223 is a high-voltage 30 mm coreless motor delivering 215.1 W at 22300 rpm from a 90 VDC supply. With 96.45 mN·m continuous torque and 2.62 A current, it is designed for demanding industrial applications such as precision machine tools, medical equipment, and high-speed automation. The four-pole, three-phase coreless construction ensures smooth, efficient operation with minimal electrical noise. Its 84 mm body length and 0.3 kg mass provide a powerful solution for high-performance motion systems.
96.45 mN·m · 215.1 W · 84 mm
No products match your current filter. Try another series or clear the search.
Why Engineers Choose Treadpace

Built for Machines That Run 24/7

Every LCISC / LCID5 motor is wound, assembled and load-tested in-house, with test data shipped alongside the motor.

All-in-1
Compact Integrated Design
Motor and drive integrated — simplifies installation, saves cabinet space and reduces wiring runs.
CIA402
Multiple Motion Modes
Position, absolute-position, speed and short-distance positioning modes compliant with CIA402.
-30 %
Low-Resistance MOS
Low-resistance MOS devices reduce drive losses and heat, extending service life of the motor.
5
Control Protocols
Pulse, RS485 / Modbus-RTU, CANopen and EtherCAT — pick the fieldbus your controller already speaks.
Inside the Factory

7,000 m² of Motor Manufacturing

Five automated production lines, in-house laboratories and 100 % end-of-line testing — from stator winding all the way to export packing.

Stator Winding Line
Stator Winding Line Automated coil winding with in-line tension and resistance monitoring.
Rotor Assembly
Rotor Assembly Magnet bonding and rotor balancing on the automated assembly line.
Drive Board SMT Line
Drive Board SMT Line Integrated drive PCB assembly and AOI inspection in a dedicated area.
Final Assembly
Final Assembly Motor, drive and encoder married into one compact housing.
End-of-Line Test Bench
End-of-Line Test Bench 100% testing — back-EMF, holding torque, insulation and temperature rise.
In-House Laboratory
In-House Laboratory Design verification, life testing and thermal chamber validation.
Quality Control
Quality Control Incoming inspection of magnets, bearings, laminations and electronics.
Packing & Logistics
Packing & Logistics Lot-traceable packing and export preparation for more than 30 countries.
By the Numbers

Treadpace Manufacturing Scale

2011
Founded
Changzhou Treadpace Co., Ltd.
7 000 m²
Manufacturing Space
Five automated production lines
2M+
Motors per Year
Approximately two million units
30+
Export Countries
Global customer base
Applications

Where Treadpace Integrated Motors Are Used

Products are exported to more than 30 countries and used across these industries. Click one to tell us about your application.

Textile Machinery
Packaging Equipment
Laser Equipment
Engraving & Printing
Advertising Equipment
Stone Processing
Ceramics
Medical Equipment
Robotics & AGVs
Automatic Doors
Apparel Machinery
Drawing & Plotting

What Design Engineers Say

We moved our packaging indexer to an LCISC86 integrated stepper-servo with 15-bit encoder. Constant torque from low to high speed — and no separate drive cabinet to wire.
RM
Rafael Moreira
Controls Engineer, Packaging Integrator
The LCISC57 dropped straight into our engraver. 1.8° step angle, 4.2 A phase current — the whole axis runs cooler and quieter.
AK
Anna Kowalski
Lead Engineer, Engraving Equipment OEM
We chose the LCID5 80 mm 1000 W servo for a lift axis. 17-bit absolute encoder and 3.2 N·m rated torque — no external driver.
TS
Takeshi Sato
Hardware Manager, Medical Device Startup
The customized linear module built around their LCISC motor matched our drawing exactly. 15-bit encoder, integrated screw, delivered tested.
MV
Marco Verhoeven
Robotics Lead, Semiconductor Equipment
Company Profile

Backed by Treadpace Manufacturing

Treadpace is a global supply partner for the Changzhou Treadpace catalog — from integrated DC servo motors to integrated stepper-servo motors and customized motion modules.

2011
Founded
Changzhou Treadpace Co., Ltd. — specialising in stepper motors and brushless DC motors.
100+
Employees
Including 12 dedicated R&D engineers supporting fast application-specific solutions.
7 000 m²
Manufacturing Space
Five automated production lines and in-house laboratories for design and process control.
2M
Motors / Year
Annual output of approximately two million motors, exported to more than 30 countries.
Request a Quote

Tell Us About Your Motion Requirement

Send us your torque, speed, frame size and protocol — we reply with a matched LCISC / LCID5 model and price within 24 hours.

We never share your details. Technical data is treated as confidential.

PDF — includes LCISC / LCID5 specification tables, dimensional drawings and driver compatibility.

Talk to an Engineer

Let's Size the Right Integrated Motor for Your Machine

Send us your load profile — we'll come back with a model, a matching protocol and a price.

Email WhatsApp
